Autel MaxiSys MS906TS
MaxiSys MS906TS is built in the Android operating system, with the best possible coverage of OE-level diagnostics and TPMS integration. Autel MS906TS has an 8” capacitive HD touch screen and long-distance wireless communication and it efficiently offers comprehensive vehicle diagnostics and analysis together with universal TPMS solutions.
Autel MS906TS TPMS Tool Features:
1. Integrated TPMS antenna module for performing comprehensive TPMS service
2. Open source Android Operating System for fast boot-up and multitasking
3. The most extensive complete system coverage for more than 80 US, Asian and European makes and models
4. Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding
5. Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding, etc.
6. Smart AutoVIN technology for identifying vehicles easily
7. Uniquely integrated TPMS service application designed for triggering known OEM TPMS sensors, programming Autel MX-Sensor and performing TPMS sensor relearn procedure.
What Can MS906TS Do For You?
Autel MS906TS comes with an advanced ECU coding function. ECU Coding allows you to establish a data link to the electronic control system of the test vehicle via the VCI device for vehicle diagnosis, service or coding. You can operate functional tests, retrieve vehicle diagnostic information such as trouble codes, event codes and live data, and perform ECU coding, for various vehicle control systems, such as engine, transmission, ABS and more. But it does NOT have ECU Programming capability.
>Comprehensive TPMS Services
Autel MaxiSys MS906TS TPMS service tool is equipped with comprehensive TPMS functions. It features an embedded TPMS antenna to activate all known TPMS sensors, one-step check TPMS sensor's health status. Autel MS906TS TPMS can read and clear DTCs and show DTC descriptions on the screen, and it also relearns and program MX-sensors.
- Activate TPMS sensors
- TPMS diagnosis, one step to do complete TPMS health check
- Read/clear TPMS DTCs; on-screen DTC description
- Scan TPMS sensor ID and copy ID into MX-Sensor
- Program MX-Sensor by auto-creating sensor ID
- Read Sensor ID by OBD and copy ID into MX-Sensor
- Relearn by OBD function
- Relearn procedure guide on the tool
- Check Key FOB
>Auto VIN Scan
Autel Maxisys MS906TS auto diagnostic scanner comes with the latest VIN-based Auto VIN Technology that enables technicians or home mechanics to identify vehicle information, like brand, year, make, model and etc, at a single touch to perform all systems diagnosis accurately and efficiently.
MS906TS comes with a Bi-directional control capability to perform active tests to determine the integrity of a system or parts like ABS, window, door, roof, by reading the ECU data, or by monitoring the operation of the actuators, such as switching a solenoid, relay.
>1-Year Free Software Update
MS906TS comes with 1 Year FREE software update and 1 Year warranty. A 24/7 online team is available for any help! MS906TS comes with unmatched vehicle coverage of more than 80 American, Asian and European vehicle makes.
30+ Service Functions Meet Your Demands
- Oil Reset
- EPB Service
- SAS Calibration
- DPF Regeneration.
- ABS/SRS Services
The Autel MaxiVCI allows the diagnostic scanner to wirelessly communicate with the DLC and connect with the USB connection. With an ultra-long working range of about 164 feet(about 50m), you can perform vehicle OE-Level All Modules diagnosis and services remotely without worrying about the cable might not be long enough or the limited space and hot air in your car.
ABS Auto Bleed
MS906TS diagnostic scanner tool comes with a useful ABS Brake Bleeding hot function that enables technicians and home mechanics to bleed air out of the ABS module and saves you time and money taking your baby to a dealership or shop.
Autel MaxiSys MS906TS — Introduction
Autel Maxisys MS906TS Hardware Specification:
|Operating System||Android™ 4.4.2, KitKat|
|Processor||Samsung Exynos T5260 6-Core Processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15)|
|Memory||2 GB RAM & 32 GB ROM|
|Display||8.0" LED capacitive touch screen with 1024x768P resolution|
|Connectivity||Wi-Fi (802.11 b/g/n)
Mini USB 2.0
Wireless BT V2.1+EDR
SD Card (support up to 32 GB)
|Camera (rear)||Rear-facing, 8.0 Megapixel, AF with Flashlight|
|Sensors||Gravity Accelerometer, Ambient Light Sensor (ALS)|
|Audio Input/Output||Microphone, Single Speaker, 3-Band 3.5 mm stereo/standard headset jack|
|Power and Battery||10,000 mAh 3.7 V lithium-polymer battery
Charging via 12 V AC/DC power supply
|Input Voltage||12 V (9-35 V)|
|Power Consumption||5 W|
|Operating Temperature||-10 to 55°C (14 to 131°F)|
|Storage Temperature||-20 to 70°C (-4 to 158°F)|
|Housing||Rubberized outer protection and rugged internal housing|
|Dimensions (W x H x D)||270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)|
|Weight NW||1.10 kg (2.42 lb.)|
|Updates||1 Year free updates online|
Autel MS906TS Package List:
- 1x AC/DC Adapter (12V)
- 1x Adapter for Benz-14 (Europe Only)
- 1x Adapter for Chrysler-16 (America Only)
- 1x User Manual
- 1x Carrying Case
- 1x MaxiVCI V100
- 1x Maxivide MV108
- 1x Quick Reference Guide
- 1x Lighter Fuse
- 1x Adapter for GM/Daewoo-12
- 1x Adapter for BMW-20
- 1x Adapter for Benz-38
- 1x Adapter for Kia-20
- 1x Adapter for Mitsubishi/Hyundai-12+16
- 1x Adapter for Nissan-14
- 1x Adapter for Honda-3
- 1x Cigarette Lighter
- 1x Adapter for VW/AUDI-2+2
- 1x Soft Cloth
- 1x Packing List
- 1x Mini USB Cable
Shipping was fast but the package arrived in damage, fortunately, the item is in perfect condition. I called the Diagmart service and they responded very quickly, and offer me compensation for the broken package. Very nice.
I programmed TPMS sensors on a 2009 Nissan rogue, able to diagnose SRS light on my 2005 Honda CRV SE, was also able to program 2 genuine Honda keys. Also has auto vin scan which saves a ton of time on OBDII cars (94+). I would recommend this to a DIY or a independent mechanic. Warning, The 906 has several variants, The 906TS has full TPMS abilities, the 906BT does not.
Great tool to have. Excepts Mini SD-Card, Plays music, has a built in camera, browse the internet works like a tablet. I love it. I listen to my music while I calmly do my diagnosis
