2 Years Update Autel MaxiIM IM508 Professional Key Fob Programming Tool With XP200 Programmer, Car Diagnostic Scanner, 22+ Services, All System Diagnositcs

Fast Free Shipping
Delivery with UPS, USPS, FedEx

30-Day Return
30 Days from Date of Delivery

1-Year Free Warranty
1 YEAR from Date of Activation
Autel MaxiIM IM508
MaxiIM IM508 is a fast, easy-to-use, and ultraportable immobilizer and key programming device. It features a powerful quad-core processor, intuitive design and straightforward interface outperforming many diagnostic tools in the market
Autel IM508 has a good mixture of key programming, full system diagnosis and car maintenance services, which makes it the perfect solution for shops and technicians who demand affordable and powerful IMMO and diagnostic services.

6 Top Reasons to Buy Autel IM508
- 2-Year Free Update Service - The IM508 purchased after August 2022 comes with a two-year free software update online. When the free update expires, you can purchase the update service. Even if you don't update, the device still can be used as normal.
- No IP Restriction - global version without IP locking problem.
- Advanced IMMO Function - It can perform IMMO ECU reset/adaptation, refresh/coding, read PIN/CS (All Key Lost), key generation, key learning, remote learning.
- OE-Level & Full-System Diagnosis - Autel IM508 Car Scanner can perform OE-Level diagnosis on all car electronic systems like ABS, SRS, Engine, Transmission, etc
- 25+ Useful Hot Service - Autel IM508 has a stunning collection of practical maintenance functions, including but not limited to Oil Reset, EPB, BMS, SAS, ABS Bleed, etc.
- Cost-Effective - IM508 has the same IMMO function as IM608 working with XP400PRO, but it is less expensive, saving you more than $1800.
AUTEL MAXIIM IM508 ADVANTAGES:
Advanced Car Key Programming
Autel IM508 is a professional car diagnostic scanner that provides extraordinary service functions for the immobilizer system, including immobilizer system status, key learning, key add, all keys lost, remote control learning, remote control add, chip read and write. It' s a professional solution for car keys and remote controls and prevents your car from being stolen!
Smart Mode– accesses to a function menu where each function is configured as a smart guide system.
Expert Mode– accesses to a function menu where each function is separated from each other.
1) Read PIN / CS (All Key Lost)
2) Key Generation
3) Key Learning
4) Remote Learning
5) Backup / Restore IMMO Data
6) IMMO ECU Reset / Adaptation
7) IMMO ECU Refresh / Coding
8) BMW FEM / BDC Key Learning and ECU Adaptation
9) VW / AUDI MQB Key Learning, 48 Transponder (96-bit) Add Key, All Key Lost, A6 All Key Lost, and More

Comprehensive IMMO Functions
Autel MaxiIM IM508 advanced key programmer scan tool can perform comprehensive IMMO functions including Reading PIN/CS(All Key Lost), Key Generation, Key Learning, Remote Learning, Benz FEM/BDC Key Learning/ECU Adaptation, BMW CAS4/3/2 Key Learning, VW/Audi/Skoda/Seat IMMO III/IV/V Add Key, All Key Lost, IMMO ECU Reset/Adaptation/Refresh/Coding


Smart Mode + Expert Mode
M508 comes with comprehensive IMMO functions that provide Smart Mode and Expert Mode to guide both professional technicians and home mechanics performing IMMO-related functions, including Key Learning, Remote Control Learning, Remote Control Add, All Key Lost and etc.
Smart Mode: Guided and automated key learning for home mechanics.
Expert Mode: Advanced key learning for professionals

Two Years Free Update Service
The Autel IM508 comes with two years of free update service so that you can keep up with Autel's latest software updates and vehicle coverage.

Autel IM508 EEPROM Read/Write Supported Types
ATMEL
AT24C01, AT24C02, AT24C04, AT24C08, AT24C16, AT24C32, AT24C64, AT24C128, AT24C256, AT24C512, AT24C1024, AT24C128_1.8, AT24C256_1.8, AT24C512_1.8, AT24C01A, AT25010, AT25020, AT25040, AT25080, AT25160, AT25320, AT25640, AT25128, AT25256, AT25512, AT25010_1.8, AT25020_1.8, AT25080_1.8, AT25320_1.8, AT25640_1.8, AT25128_1.8, AT25256_1.8, AT59C11, AT59C22, AT93C46A, AT59C13, AT93C46, AT93C46R, AT93C56, AT93C57, AT93C66, AT93C76, AT93C86
CATALYST
CAT25C01, CAT25C02, CAT25C04, CAT25C08, CAT25C16, CAT25C32, CAT25C64, CAT25C128, CAT25C256
FAIRCHILD
NM24C16U, NM24C16UT, NM24C17U, NM24C17UT, FM93CS46T
MICROCHIP
85C72, 85C82, 85C92, 25xx080, 25xx160, 25xx320, 25xx640,25xx040_TSSOP, 25xx320_TSSOP, 25xx640_TSSOP, 93C06, 25xx040, 93C46X, 93C46A, 93C46, 93C46AX, 93C46BX, 93C46CX, 93C56A, 93C56, 93C66A, 93C66, 93C76A, 93C76, 93C86A, 93C86
NXP
PCF8582C, PCF8594C, PCF8598C
NATIONAL
NM93C13, NM93C14, NM93CS06, NM93C14TM8, NM93CS46, NM93CS56, NM93CS66
OKI
MSM16911
SONY
CXK1011, CXK1012, CXK1013
Seiko
S_24S45, S_24H30, S_24H30_SOP8, S_24H45, S_24H45_SOP8, S_24S30
ST
M24C01, M24C02, M24C04, M24C08, M24C16, M24C32, M24C64, ST24x01/ ST25x01, ST24x02/ ST25x02, ST24x04/ ST25x04/ ST24x08/ ST25x08, ST24x16, ST25x16, AT25040_1.8, AT25160_1.8, M95010, M95020, M95160, M95040, M95080, M35080, M95320, M95640, M95256, M95128, M95512, M93C46, M93C56, M93C66, M93C76, M93C86, M93S46, M93S56, M93S66
TOSHIBA
TC89101, TC89102, TC89121, TC89122
TMC
TMC93LC46, TMC93LC56, TMC93LC57, TMC93LC66, TMC93LC86
XICOR
X5043, X5045, X25043, X25045, X24C44
9S12 Read/ Write Supported Types
FREESCALE
MC9S12DG128
22+Most Commonly Used Maintenance Services
Autel IM508 key programmer diagnostic scanner has a stunning collection of practical maintenance functions, including but not limited to Oil Reset, EPB, BMS, SAS, ABS Bleed, etc.
Oil Rest Service: This function allows you to perform a reset for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle's driving conditions and climate. The Oil Life Reminder must be reset every time the oil is changed, so the system can calculate when the next oil change is required.
EPB Service: This function has a multitude of usages to maintain the electronic braking system safely and effectively. The applications include deactivating and activating the brake control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.
SAS Service: Steering Angle Sensor Calibration permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM. Therefore, the front wheels and the steering wheel must be set exactly to the straight-ahead position before calibration.
TPMS Service: This function allows you to quickly lookup the tire sensor IDs from the vehicle's ECU, as well as to perform TPMS replacement and sensor tests.
BMS Service: The BMS (Battery Management System) allows the scan tool to evaluate the battery charge state, monitor the close-circuit current, register the battery replacement, and activate the rest state of the vehicle.
DPF Service: This function is used to manage DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit.
Full-System Diagnosis
Autel IM508 diagnostic tool can scan all the vehicle modules, including but not limited to PCM, ECM, EPS, PDM, BCM, TPM, SCCM and covers prime systems such as ABS, SRS, Engine Systems, Transmission systems, Brake systems, etc.

Wide Vehicle Coverage
Autel IM508 key programmer is compatible with 80+ US, Asian, and European makes and models such as Toyota, Honda, Infiniti, Kia, Nissan, Subaru, Suzuki, Mazda, Lexus, Dodge, Bentley, Seat, Skoda, and more.

Auto VIN Scan
The MaxiIM IM508 key programmer diagnostic system features the latest VIN-based Auto VIN Scan function to identify vehicles and it is applied to IMMO, Programming, Diagnostic, and Service functions.

Autel IM508 Package Includes:
1 X IM508 Key Programming Scan Tool,1 X AAC001-MED17 Cable,
1 X Mazda-17 Adaptor,
1 X KIA-10 Adaptor,
1 X Main cable,
1 X Carrying Case,
What Can XP400 Pro Do for You?
- Added with more functionality for BMW, BENZ, as well as more powerful functions on EEPROM, MCU, ECU reading/writing
- read/write data of over 3,000 Chip Type to mostly satisfying your needs. Added with more functionality for BMW, BENZ, as well as more powerful functions on EEPROM, MCU, ECU reading/writing
- When it's connected to Autel XP400pro, IM508 Key Programming Scan Tool can extend its programming capabilities to the next level, such as IMMO ECU Read & Write, MC9S12 Encryption Chip Read & Write, IC Card Read & Write, Mercedes Infrared Key Read & Write, Remote Frequency Detect.
- Supports Key Renewal on 11 Key Types with Additional Adapters - IMKPA Key Programming Accessories Kit
Update:
Newly added features on Autel IM508:
For Fiat:
1.Adds Key Learning (Bypass PIN)Function for Argo (2017-2020), Cronos (2017-2020),Toro (2016-2020),Mobi (2016-2019) and New Fiorino (2008-2019)[Globallnitial Launch]
2. Adds Key Learning for Blade Key Function for Awventura (2014-2018). [GlobalInitial Launch]
3. Adds Key Learning for Blade Key Function for 500x (2018-2020), Area (2018-2020), and Tipo(2018-2020)
For BMW:
1. Supports New Software Version (swfl_00002419_085_010_080) for KeyLearning Function for FEM/BDC Immobilizer System.[Global Initial Launch]
2. Adds 196 Software Versions, Supporting Read ISN (OBD Mode) Function forB48/B58 Engine.[Global Initial Launch]
2. GM Software Updated to V2.90
1) All Key Lost via OBD
* Support all models up to 2020, smart & Blade keys
* APPLICABLE TO ALL AUTEL IM PRODUCTS, INCLUDING IM608. IM508 AND MAXISYS IM
2) Support Models:
* CHEVROLET SILVERADO
* CHEVROLET CAMARO
* GMC SIERRA
* CHEVROLET EQUINOX
* CHEVROLET TRAVERSE
* CADILLAC XT5
* CHEVROLET CRUZE
* CHEVROLET TAHOE
Autel IM508 Features:
- Advanced Key Programming
- PIN / CS Reading (Full Lost)
- Key Generation
- Key Programming
- Command Introduction
- Backup / Repair IMMO Data
- IMMO ECU Reset / Adaptation
- IMMO ECU Regeneration / Coding
- BMW FEM / BDC Key
- Programming and ECU Adaptation
- VW / AUDI MQB Key Programming, 48 Transponder (96-bit) Key Copy, Full Lost, A6 Full Lost and More
- 1 Year Free Update Online
- 2021 Latest version
- Support Muti-Language: English / Portuguese / Germany / Japanese / French / Spanish
New Key Programming/IMMO Tools: IM608 & IM508
Autel MaxiIM IM508 Key Programmer Specifications:

Operating System | AndroidTM 4.4.4 |
Processor | Cortex-A9 processor (1.6 GHz) |
Memory | 32GB |
Display | 7-inch LCD capacitive touchscreen with 1024x600 resolution |
Connectivity | Mini USB 2.0 USB 2.0 Wi-Fi Micro SD card (supports up to 32GB) |
Sensors | Ambient light sensor for brightness auto changing |
Audio Input / Output | Input: N/A Output: buzzer |
Power and Battery | 3.7 V/5000 mAh lithium-polymer battery, Charges via 5 VDC power supply |
Tested Battery Life | Around 4.5 hours of continuous use |
Battery Charging Input | 5 V/1.5 A |
Power Consumption | 500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V |
Operating Temp. | 0 to 50°C (32 to 122°F) |
Storage Temp. | -20 to 60°C (-4 to 140°F) |
Operating Humidity | 5% - 95% non-condensing |
Net Weight | 788 g (2.42 lb.) |
Download |
Autel MaxiIM IM508 User Manual |
Update Service | 2-Year Free Software Update |
Product Display
Full-System Diagnosis
Autel IM508 diagnostic tool can scan all the vehicle modules, including but not limited to PCM, ECM, EPS, PDM, BCM, TPM, SCCM and covers prime systems such as ABS, SRS, Engine Systems, Transmission systems, Brake systems, etc.

Wide Vehicle Coverage
Autel IM508 key programmer is compatible with 80+ US, Asian, and European makes and models such as Toyota, Honda, Infiniti, Kia, Nissan, Subaru, Suzuki, Mazda, Lexus, Dodge, Bentley, Seat, Skoda, and more.

Auto VIN Scan
The MaxiIM IM508 key programmer diagnostic system features the latest VIN-based Auto VIN Scan function to identify vehicles and it is applied to IMMO, Programming, Diagnostic, and Service functions.

Autel IM508 Package Includes:
1 X IM508 Key Programming Scan Tool,1 X AAC001-MED17 Cable,
1 X Mazda-17 Adaptor,
1 X KIA-10 Adaptor,
1 X Main cable,
1 X Carrying Case,
What Can XP400 Pro Do for You?
- Added with more functionality for BMW, BENZ, as well as more powerful functions on EEPROM, MCU, ECU reading/writing
- read/write data of over 3,000 Chip Type to mostly satisfying your needs. Added with more functionality for BMW, BENZ, as well as more powerful functions on EEPROM, MCU, ECU reading/writing
- When it's connected to Autel XP400pro, IM508 Key Programming Scan Tool can extend its programming capabilities to the next level, such as IMMO ECU Read & Write, MC9S12 Encryption Chip Read & Write, IC Card Read & Write, Mercedes Infrared Key Read & Write, Remote Frequency Detect.
- Supports Key Renewal on 11 Key Types with Additional Adapters - IMKPA Key Programming Accessories Kit
Update:
Newly added features on Autel IM508:
For Fiat:
1.Adds Key Learning (Bypass PIN)Function for Argo (2017-2020), Cronos (2017-2020),Toro (2016-2020),Mobi (2016-2019) and New Fiorino (2008-2019)[Globallnitial Launch]
2. Adds Key Learning for Blade Key Function for Awventura (2014-2018). [GlobalInitial Launch]
3. Adds Key Learning for Blade Key Function for 500x (2018-2020), Area (2018-2020), and Tipo(2018-2020)
For BMW:
1. Supports New Software Version (swfl_00002419_085_010_080) for KeyLearning Function for FEM/BDC Immobilizer System.[Global Initial Launch]
2. Adds 196 Software Versions, Supporting Read ISN (OBD Mode) Function forB48/B58 Engine.[Global Initial Launch]
2. GM Software Updated to V2.90
1) All Key Lost via OBD
* Support all models up to 2020, smart & Blade keys
* APPLICABLE TO ALL AUTEL IM PRODUCTS, INCLUDING IM608. IM508 AND MAXISYS IM
2) Support Models:
* CHEVROLET SILVERADO
* CHEVROLET CAMARO
* GMC SIERRA
* CHEVROLET EQUINOX
* CHEVROLET TRAVERSE
* CADILLAC XT5
* CHEVROLET CRUZE
* CHEVROLET TAHOE
Autel IM508 Features:
- Advanced Key Programming
- PIN / CS Reading (Full Lost)
- Key Generation
- Key Programming
- Command Introduction
- Backup / Repair IMMO Data
- IMMO ECU Reset / Adaptation
- IMMO ECU Regeneration / Coding
- BMW FEM / BDC Key
- Programming and ECU Adaptation
- VW / AUDI MQB Key Programming, 48 Transponder (96-bit) Key Copy, Full Lost, A6 Full Lost and More
- 1 Year Free Update Online
- 2021 Latest version
- Support Muti-Language: English / Portuguese / Germany / Japanese / French / Spanish
New Key Programming/IMMO Tools: IM608 & IM508
Autel MaxiIM IM508 Key Programmer Specifications:

Operating System | AndroidTM 4.4.4 |
Processor | Cortex-A9 processor (1.6 GHz) |
Memory | 32GB |
Display | 7-inch LCD capacitive touchscreen with 1024x600 resolution |
Connectivity | Mini USB 2.0 USB 2.0 Wi-Fi Micro SD card (supports up to 32GB) |
Sensors | Ambient light sensor for brightness auto changing |
Audio Input / Output | Input: N/A Output: buzzer |
Power and Battery | 3.7 V/5000 mAh lithium-polymer battery, Charges via 5 VDC power supply |
Tested Battery Life | Around 4.5 hours of continuous use |
Battery Charging Input | 5 V/1.5 A |
Power Consumption | 500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V |
Operating Temp. | 0 to 50°C (32 to 122°F) |
Storage Temp. | -20 to 60°C (-4 to 140°F) |
Operating Humidity | 5% - 95% non-condensing |
Net Weight | 788 g (2.42 lb.) |
Download |
Autel MaxiIM IM508 User Manual |
Product Display
Shipping
Free Shipping on All Orders Without Any Tax.
All orders are processed and shipped out within 24 hours of being placed. Once your order has been shipped out, we will provide you with a tracking number so that you can easily track your package and stay updated on its delivery status. With this tracking number, you'll be able to see the expected delivery date and have peace of mind knowing exactly when your package will arrive.
Fast Shipping from Local Warehouse: Receive Your Order in 5-7 Days!

Returns
30 calendar days from the date you received it
If, for any reason, you are not satisfied with your purchase or if the product does not meet your expectations, you can return it within 30 calendar days from the date you received it. To qualify for a refund, please ensure that the product is returned in its original packaging along with the original purchase receipt.
Our team will be glad to assist you with the return process and issue a refund once we have received the returned product. Customer satisfaction is our top priority, and we strive to ensure that all of our customers are happy with their purchases from diagmart.com.
Waranty
one (1) year limited warranty
At DiagMart, we stand behind the quality of our products and offer a one (1) year limited warranty on all products sold exclusively on diagmart.com.
This limited warranty provides coverage for defective workmanship or materials in your product and is your exclusive remedy. If your product is found to be defective during the warranty period, we will repair or replace it free of charge.
Please note that this warranty only applies to products purchased directly from diagmart.com and does not cover damage caused by misuse, accidents, or normal wear and tear.
We are committed to ensuring our customers have a positive experience with our products and services. If you have any questions or concerns about the warranty or need assistance with a warranty claim, please don't hesitate to contact our customer support team.
Q:Where are my orders shipped from?
A:Your order will be shipped from California or New York. If you want it to be shipped from a specific place, please let us know in advanced.
Q: If the one year free update expires, will it stop working?
A:You can still use your tool as usual even the one year update expires. It will not impact the normal usage of the tool. But, if you need the newest vehicle covrage, it's better to update.
Q: How do I know wether this tool cover the vehicles I want?
A:Generally, our tools are compatible with all the OBD2 vehicles, but functions may differ depending on vehicle makes and models. Please let us contact us and provide the VIN and vehicle make and model so that we can tell you the functions it supports.
Q: Can I return the item if I realize that it does not fit my purpose?
A:Yes, you can return the item within 30 days from the date you receive the it.
The Advantages For Software Update:
- Take advantage of new features and functions as they roll out from Autel.
- Expand coverage for the latest vehicle makes and models.
- Reduce out-of-pocket device repair costs as well as shop downtime.

How To Purchase And How Do We process Your Order?
Choose the Update service you needed and Checkout. Once finish your payment, please send your Tablet S/N number and your order number to our email "sales@diagmart.com" . We will authorize your update online and send you a notification. And then, you are able to update the software on the device.
Why Should You Buy From Us?
Product | Our Prices | Market Prices |
MK908 Update | $599 | $999 |
MS Ultra Update | $899 | $1459 |
MK906BT Update | $375 | $679 |
MS919 Update | $810 | $1299 |
MS909 Update | $729 | $1269 |
MS908SP Update | $659 | $1,295 |
MaxiSys Elite Update | $609 | $1,295 |
MaxiSys CV Update | $989 | $1,295 |
MS906TS Update | $599 | $795 |
MS906BT Update | $389 | $695 |
MS906 Update | $299 | $495 |
MK908P Update | $639 | $899 |
DS808/DS808K Update | $299 | $350 |
MS908 Update | $719 | $999 |
TS608 Update | $499 | $600 |
MK808BT Update | $110 | $299 |
MX808 Update | $80 | $125 |
MK808TS Update | $210 | $295 |
MP808K Update | $359 | $439 |
IM608 Update | $609 | $1299 |
IM508 Update | $259 | $599 |
